| Engine System |
| Engine Type |
60cc, Automatic, Single cylinder, 4 stroke, Air cooled |
| Displacement |
60 ml |
| Shift Type |
Automatic clutch, One gear |
| Start Type |
Electric Start Only |
| Bore x Stroke |
Ф52.4×49.5mm |
| Max Power |
1.8 / 7000 kw/r/min |
| Max Torque |
2.4 / 6500 N.m/r/min |
| Compression Ratio |
10 : 1 |
| Engine Oil #： |
SJ5W一30 |
| Ignition |
CDI |
| Drive Train |
#T8F，14/74T |
| Size Data |
| Overall Size(L*W*H) |
1270*590*780mm/50"X23.23"X30.71" |
| Wheel Base |
34.84" |
| Seat Height |
22.05" |
| Ground Clearance |
7.09" |
| Fuel Capacity |
1.8L / 0.4 Gal. |
| Wheels |
Fr. & Rr. Both Steel 1.40×10/￠12 Rims, Cast Hubs and Rim |
| Tire |
Fr. & Rr. Both 2.50x10 ,Knobby tires |
| Frame/Suspension/Brake system |
| Frame |
Cradle Type Steel Tube Frame |
| Front Fork |
L=520mm Inverted Hydraulic Non Adjustable Forks, 50mm Travel |
| Rear Shock |
L=200mm Non Adjustable Shock, 30mm Travel |
| Swing-Arm |
Forged Steel Swingarm |
| Handle Bar |
Steel handle bar |
| Front Brake |
Mechanical Brakes, 140mm Disc |
| Rear Brake |
Mechanical Brakes, 140mm Disc |
| Exhaust |
Aluminium Alloy Exhaust Pipe |
| Packing and Loading |
| Packing Size |
44.1*12.6*22.44 inch |
| N.W/LBS |
72.6 LBS |
| G.W/LBS |
81.4 LBS |
|
|
| Other Features: |
With Training Wheels |
