196cc 6.5hp, GX200 compatible engine requires minimal maintenance.
Rear Disc Brake, a feature that sets it apart from other minibikes.
This model operates on a rear-wheel chain drive and offers endless entertainment for all ages. With over two decades of experience, TrailMaster continues to deliver exceptional products, including the retro-inspired Storm 200 minibike designed for longevity.
Specifications
- Engine Displacement: 196cc 6.5 HP
- CARB Approved
- Starting: Recoil Cord
- Spark Plug Type: Torch - F7RTC
- Cooling: Air cooled
- Ignition Type T.C.I
- Cylinder head config.: OHV
- Number of Cylinders: Single
- Combustion Cycle: 4-stroke
- Bore and Stroke: 68 x 54mm
- Compression Ratio: 8.5:1
- Rated Power 7.7kw @ 3600rpm
- Rated Torque: 13.5Nm @ 2500rpm
- Idle Speed 1500 ± 100 rpm
- Top Speed 30-35mph
- Drive System Type: Chain Drive
- Gear Ratio: Centrifugal clutch
- Rear Brakes Mechanical Disc
- Tires: Front Tire Size AT145/70-6; Rear Tire Size AT145/70-6
- Fuel Gas Tank Capacity: 0.81gal.
- Fuel type Unleaded 87 octane or higher
- Oil Capacity .53qt. (.5L)
- Oil Type SAE 10W-40
Dimensions & Weights
- Length x Width x Height: 51.2” x 25.6”x 35.4”
- Seat Height: 25.2”
- Ground Clearance: 6”
- Vehicle Net Weight: 103lbs
- Weight Capacity: 250lbs
- Crate dimension: 53”x23”x18”
- Shipping Weight: 130lbs (With pallet: 170lbs)
*Seat color may vary
